Electric 48V 12 Seater Golf Cart , Battery Powered Club Car Electric Golf Cart

Product Categories
TOP EXCELLENT CAR CO.,LTD
Contact Now

Electric 48V 12 Seater Golf Cart , Battery Powered Club Car Electric Golf Cart

  • 1
  • 2
  • 3

Brand Name : TOPCART

Model Number : TG－11

Certification : CE

Place of Origin : CHINA

MOQ : 1 UNIT

Price : Negotiable

Payment Terms : Western Union, L/C, T/T

Supply Ability : 500 UNITS PER MONTH

Delivery Time : 10-15 WORK DAYS

Packaging Details : EXPORTED PACKAGE

Slope Climbing Capacity : 25%

Power Fuel： : Electric

Type： : Buggy/Golf Carts

Specification : EU standards appoved

Condition : New

Main Markets : Main Markets

Contact Now



Electric 48V 12 Seater Golf Cart With Battery Power For Transportation




Specifications



  • Chassis: steel
  • Crust material: fiber glass steel and HDPE
  • Overall dimensions (L x W x H): 4,640 x 1,300 x 1,220mm
  • Front/rear tread: 940/990mm
  • Wheelbase: 3,680mm
  • Curb weight: 770kg
  • Carrying capacity: 800kg
  • Front/rear tire: journey, 225/55B12, 6P
  • Ground clearance: 150mm (minimum)
  • Turning radius: Speed: 25km/hour (maximum)
  • Travel distance: 55km (maximum)
  • Driven type: back wheel driving
  • Brake distance: Slope climbing capacity: 30%
  • Gather: 3 to 5mm
  • Steering system: mechanical steering
  • Cushion material: poly-foam
  • Seating capacity: 8
  • Motor: 48V DC, 4kW
  • Batteries: 8V 170Ah x6
  • Single battery weight: 30kg
  • Charger: 48V/18A
  • Charge time: 10 to 12 hours
  • Accelerator: adjustable inductive accelerator continuously variable speed system
  • Controller: American Curtis electronics controller

Wiper
Optional color: White, yellow, green, red, black, gold, navy blue,


Main description


Premium Components throughout

Aluminum Chassis and Fabrication to avoid common rust / corrosion issues

Global Customer support

Engineered in the USA and built to strict specifications

Superior workmanship with attention to details

Wide selection of models available

Recognized industry leader in solar canopy interface

Powerful AC motor – superior to unreliable Chinese motors commonly offered

Full Warranty



Competitive advantage

1. Hot-Galvanized-DIP --- 15 years no rust gurantee for hot-galvanized-DIP frame and the cost is much more lower than aluminum;
2. Independent suspension with two arms --- It is Safe and comfortable for independent suspension with two arms;
3. Battery tray --- Battery tray can protect the batteries and prevent the electrolyte from rusting the frame;
4. Both mechanical and hydraulic brake (two options) --- All the automobiles are with hydraulic brake including BMW, brake distance is shorter and people feel comfortable when braking;
5. 10' Aluminum --- No rust for aluminum wheels, and bigger wheels look nice;
6. On-board smart charger from same manufacture of Delta-q (the Canadian name brand) --- On-board charger is convenient that customers can charge the car where there is a socket, the price includes this on-board charger.

Electric 48V 12 Seater Golf Cart , Battery Powered Club Car Electric Golf Cart

Electric 48V 12 Seater Golf Cart , Battery Powered Club Car Electric Golf Cart
